Specifications
Overview
Accuracy
±2°C (±3.6°F) or ±2% of reading for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Alarm
Moisture, insulation, and measurement
Color alarm (isotherm)
Above, below, interval, condensation, insulation
Detector Type
Uncooled microbolometer, 17µm
Dimensions (L x W x H)
278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in)
IR Resolution
240 × 180 (43,200 pixels)
Laser Pointer
Yes; dedicated button
Object Temperature Range
-20°C to 120°C (-4°F to 248°F) 0°C to 650°C (32°F to 1200°F)
Compass GPS
Yes; automatic GPS image tagging
Area Box
1 in live mode
Connections & Communications
Communication Interfaces
USB 2.0, Bluetooth, Wi-Fi, DisplayPort
Storage Media
Removable SD card
Video Out
DisplayPort over USB Type-C
METERLiNK
Yes; several readings
Environmental
Operating Temperature Range
-15°C to 50°C (5°F to 122°F)
Storage Temperature Range
-40°C to 70°C (-40°F to 158°F)
Imaging & Optical
Color palettes
Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
Digital Camera
5 MP, 53° × 41° FOV
Digital Zoom
1-4x continuous
f-number
f/1.3
Field of view (FOV)
24° × 18°
Focus
Manual
Image Fequency
30 Hz
Image Modes
Infrared, visual, MSX®, Picture-in-Picture
Non-radiometric IR video streaming
H.264 or MPEG-4 over Wi-Fi; MJPEG over UVC or Wi-Fi
Picture-in-Picture
Centered infrared area on the visual image
Radiometric IR video recording
Real-time radiometric recording (.csq)
Radiometric IR video streaming
Over UVC
Spectral Range
7.5 – 14.0 µm
Weight [incl lens]
1 kg (2.2 lbs)
MSX
Embosses visual details on full resolution thermal image
Non-Radiometric IR & Visual Video Recording
H.264 to memory card
Measurement & Analysis
Measurement Presets
No measurement, center spot, hot spot, cold spot, 3 spots, hot spot-spot
Spot Meter
3 in live mode
Thermal Sensitivity
<0.04°C at 30°C (86°F), 24° lens
Meter Data
Display
4°, 640 × 480 pixel touch screen LCD with auto-rotation
Other
Shock and Vibration and Drop and Encapsulation
25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1
Power
Battery operating time
Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use
Battery type
Li-ion battery, charged in camera or on separate charger
Shipping Information
Packaging
Infrared camera with lens, battery (2 ea), battery charger, front protection, straps (hand, wrist), hard transport case, lanyards, lens caps, lens cleaning cloth, power supplies, 8 GB SD card, Torx wrench, cables (USB 2.0 A to USB Type-C, USB Type-C to USB Type-C, USB Type-C to HDMI)
Storage Media
Image File Format
Standard JPEG with measurement data included
